▪ medium Format, high SPL, variable dispersion
▪ one 6.5" N-Dym cone transducer with 1.75" voice coil
▪ one 1" N-Dym Hi-driver with 1.5" voice coil
▪ variable Dispersion (hxv 110°x60°)
▪ high efficient and optimised frequency dividing network with HP RMS limiter
▪ audio Bandwidth 60Hz – 20KHz, SPL Peak >124dB/1m
▪ can be operated without DAL Control & Drive System
The S6N system is a compact 2-way constant coverage point source with passive frequency dividing network in a ported cabinet made of waterproof glued plywood with textured PU coating. The S6N provides a coverage (h x v) of 110°x 60°. The system is protected by a robust protective grille with foam inlay. One integrated grip hole is provided for an easier handling. The S6N system is primarily intended for fixed installation, but can be ordered with PU coating for mobile use. In stand-alone or spaced array operation, it can be used as a main, support or e?ect speaker. Due to its neutral reproduction characteristics and the high maximum SPL Level, it is equally suitable for speech and music transmission. For low end support, the DAL Sub-Low systems, BR12N is suitable. Featuring a high e?icient 6,5" NDym cone driver with 1.5"voice coil and an NDym 1" driver with 1.75"voice coil on a rotatable horn, the S6N system provides an audio bandwidth of 80Hz - 20KHz with a Peak power handling of 300W.
The S6N systems can be operated without the DAL Control & Drive Systems. When operated with the DAL Control & Drive System, the system is optimal parameterized for sonic quality and protected for maximum continuous and peak sound pressure level. The DAL Control & Drive Systems provide di?erent settings for the operation of S6N combinations.
The S6N o?ers a wide horizontal dispersion for stand-alone operation.
The S6NN is also suitable for tight clustering and arraying with the horn rotated to narrow horizontal dispersion (h x v 2 x 50° x 110°).
|
